6N137S Optocoupler DIP8 6N137S Optocoupler DIP8 6N137S Optocoupler DIP8
6N137S Optocoupler DIP8
VCEO(V):7V
IC(mA):50mA
VR(V):5V
IF(mA):25mA
Package:SMD-8

Product Details

Our advantages

Chinese manufacturing processes have undergone years of iteration, resulting in mature and reliable technologies. Many international corporations opt for production outsourcing in China. As an electronic co mponents manufacturer in China, our products can fully replace those of major international brands in 99% of applications without the need for testing verification. Our products boast high consistency in quality, reasonable pricing, ample inventory, flexible supply, short lead times, and professional after-sales service.


Description

The 6N137,SL2601,SL2611 series combine an AIGaAs infrared emitting diode as the emitter which is optically coupled to a silicon high speed integrated photo-detector logic gate with a strobable output in a plastic DIP8 package with different lead forming options.

Features

●High isolation 5000 VRMS

●DC input with logic gate output

●Operating temperature range -55℃ to 100°C

●REACH compliance

●Halogen free (Optional)

●MSL class 1

●Regulatory Approvals(Pending Approved)

●UL-UL 1577

●VDE-EN60747-5-5(VDE0884-5)

●CQC-GB4943.1,GB8898

●cUL-CSA Component Acceptance Service Notice No.5A


Applications

●Ground loop elimination

●LSTTL to TTL,LSTTL or CMOS

●Line receiver,data transmission

●Data mutiplexing

●Switching power supply

●Pulse transformer repacement

●Computer-peripheral interface
